225603Representative image of the familyRubber swivel castor Ø125×37.5 mm with brake
Ruedas en goma antihuella, núcleo en polipropileno, soporte giratorio taladro pasador NL freno delantero
Tellure description: 22 125X37,5 CB SRF/NL+FA C1
- Diameter (D)
- Ø 125mm
- Width (F)
- 37.5mm
- Load at 4 km/h
- 110daN
- Tread
- Rubber
Price on request
Add it to your cart and request a quote: pricing depends on customer profile and volume.
Datasheet (PDF)Official Tellure Rôta datasheet (Spanish)
Questions about this article?
Genuine Tellure Rôta product · Made in Italy
Technical specifications
Wheel
- Code
- 225603
- Series
- Tellure Rôta 22
- Tread
- Rubber
- Diameter (D)
- 125 mm
- Width (F)
- 37.5 mm
- Load at 4 km/h
- 110 daN
- Bearing
- Plain bore
Bracket
- Bracket type
- Swivel
- Fitting
- Bolt hole
- Bracket material
- Galvanised steel
- Brake
- Yes
- Brake type
- Front brake
Other sizes in this family
Ruedas en goma antihuella, núcleo en polipropileno, soporte giratorio taladro pasador NL freno delantero
15 articles
| Code | Ø × F | Load capacity | Bearing | Brake | Tellure description |
|---|---|---|---|---|---|
| 225601 | Ø80×25 mm | 65 daN | C/B | Yes | 22 80X25 CB SRF/NL+FA C1 |
| 225621 | Ø80×25 mm | 65 daN | C/R | Yes | 22 80X25 CR SRF/NL+FA C1 |
| 225602 | Ø100×30 mm | 80 daN | C/B | Yes | 22 100X30 CB SRF/NL+FA C1 |
| 225622 | Ø100×30 mm | 80 daN | C/R | Yes | 22 100X30 CR SR/F/NL+FA C1 |
| 225603 | Ø125×37.5 mm | 110 daN | C/B | Yes | This article |
| 225623 | Ø125×37.5 mm | 110 daN | C/R | Yes | 22 125X37,5 CR SRF/NL+FA C1 |
| 225604 | Ø140×37.5 mm | 120 daN | C/B | Yes | 22 140X37,5 CB SRF/NL+FA C1 |
| 225624 | Ø140×37.5 mm | 120 daN | C/R | Yes | 22 140X37,5 CR SRF/NL+FA C1 |
| 225611 | Ø150×40 mm | 130 daN | C/B | Yes | 22 150X40 CB SRF/NL+FA C1 |
| 225631 | Ø150×40 mm | 130 daN | C/R | Yes | 22 150X40 CR SRF/NL+FA C1 |
| 225610 | Ø160×40 mm | 150 daN | C/B | Yes | 22 160X40 CB SRF/NL+FA C2 |
| 225630 | Ø160×40 mm | 150 daN | C/R | Yes | 22 160X40 CR SRF/NL+FA C2 |
| 225605 | Ø180×45 mm | 180 daN | C/B | Yes | 22 180X45 CB SRF/NL+FA C2 |
| 225606 | Ø200×50 mm | 225 daN | C/B | Yes | 22 200X50 CB SRF/NL+FA C2 |
| 225626 | Ø200×50 mm | 225 daN | C/R | Yes | 22 200X50 CR SRF/NL+FA C2 |
