538203Representative image of the familyDrawing dimensions
- DDiameter
- 125 mm
- FWidth
- 37.5 mm
- HOverall height
- 156 mm
- GPlate diameter
- 73 mm
- GGThrough-hole diameter
- 12 mm
- ESwivel offset
- 37 mm
- OBrake swing radius
- 120 mm
Letters as on the drawing. Dimensions from the Tellure Rôta datasheet.
Rubber swivel castor Ø125×37.5 mm with brake
Standard rubber wheels, twin pressed-steel rim centre
Tellure description: 53 125X37,5 CB SRF+FA C1
- Diameter (D)
- Ø 125mm
- Width (F)
- 37.5mm
- Load at 4 km/h
- 130daN
- Tread
- Rubber
Price on request
Add it to your cart and request a quote: pricing depends on customer profile and volume.
Datasheet (PDF)Official Tellure Rôta datasheet (Spanish)
Questions about this article?
Genuine Tellure Rôta product · Made in Italy
Technical specifications
Wheel
- Code
- 538203
- Series
- Tellure Rôta 53
- Tread
- Rubber
- Diameter (D)
- 125 mm
- Width (F)
- 37.5 mm
- Load at 4 km/h
- 130 daN
- Bearing
- Plain bore
Bracket
- Bracket type
- Swivel
- Overall height (H)
- 156 mm
- Fitting
- Bolt hole
- Bracket material
- Galvanised steel
- Brake
- Yes
- Brake type
- Front brake
Other sizes in this family
Standard rubber wheels, twin pressed-steel rim centre
16 articles
| Code | Ø × F | Load capacity | Bearing | Brake | Tellure description |
|---|---|---|---|---|---|
| 538201 | Ø80×25 mm | 65 daN | C/B | Yes | 53 80X25 CB SRF+FA C1 |
| 538221 | Ø80×25 mm | 65 daN | C/R | Yes | 53 80X25 CR SRF+FA C1 |
| 538202 | Ø100×30 mm | 80 daN | C/B | Yes | 53 100X30 CB SRF+FA C1 |
| 538222 | Ø100×30 mm | 80 daN | C/R | Yes | 53 100X30 CR SRF+FA C1 |
| 538203 | Ø125×37.5 mm | 130 daN | C/B | Yes | This article |
| 538223 | Ø125×37.5 mm | 130 daN | C/R | Yes | 53 125X37,5 CR SRF+FA C1 |
| 538204 | Ø140×37.5 mm | 150 daN | C/B | Yes | 53 140X37,5 CB SRF+FA C1 |
| 538224 | Ø140×37.5 mm | 150 daN | C/R | Yes | 53 140X37,5 CR SRF+FA C1 |
| 538211 | Ø150×40 mm | 170 daN | C/B | Yes | 53 150X40 CB SRF+FA C1 |
| 538231 | Ø150×40 mm | 170 daN | C/R | Yes | 53 150X40 CR SRF+FA C1 |
| 538210 | Ø160×40 mm | 180 daN | C/B | Yes | 53 160X40 CB SRF+FA C2 |
| 538230 | Ø160×40 mm | 180 daN | C/R | Yes | 53 160X40 CR SRF+FA C2 |
| 538205 | Ø180×45 mm | 200 daN | C/B | Yes | 53 180X45 CB SRF+FA C2 |
| 538225 | Ø180×45 mm | 200 daN | C/R | Yes | 53 180X45 CR SRF+FA C2 |
| 538206 | Ø200×50 mm | 230 daN | C/B | Yes | 53 200X50 CB SRF+FA C2 |
| 538226 | Ø200×50 mm | 230 daN | C/R | Yes | 53 200X50 CR SRF+FA C2 |
