Tellure Rôta 635465 – Vulkollan® swivel castor Ø180×50 mm with brake635465Representative image of the family
Tellure RôtaCode 635465Series 63GH

Vulkollan® swivel castor Ø180×50 mm with brake

Ruedas de poliuretano Vulkollan®, núcleo de hierro fundido, soporte giratorio pletina NL con freno delantero

Tellure description: 63GH 180X50 CC SRP/NL+FA R2.0

Diameter (D)
Ø 180mm
Width (F)
50mm
Load at 4 km/h
300daN
Tread
Vulkollan®

Price on request

Add it to your cart and request a quote: pricing depends on customer profile and volume.

Datasheet (PDF)Official Tellure Rôta datasheet (Spanish)

Questions about this article?

926 550 642Contact →

Genuine Tellure Rôta product · Made in Italy

Technical specifications

Wheel

Code
635465
Series
Tellure Rôta 63GH
Tread
Vulkollan®
Diameter (D)
180 mm
Width (F)
50 mm
Load at 4 km/h
300 daN
Bearing
Ball bearings 2Z

Bracket

Bracket type
Swivel
Fitting
Top plate
Bracket material
Galvanised steel
Brake
Yes
Brake type
Front brake

Other sizes in this family

Ruedas de poliuretano Vulkollan®, núcleo de hierro fundido, soporte giratorio pletina NL con freno delantero

7 articles

CodeØ × FLoad capacityBearingBrakeTellure description
635451Ø80×28 mm200 daNC/C 2ZYes63GH 80X28 CC SRP/NL+FA R1.0
635452Ø100×38 mm200 daNC/C 2ZYes63GH 100X38 CC SRP/NL+FA R1.0
635453Ø125×38 mm220 daNC/C 2ZYes63GH 125X38 CC SRP/NL+FA R1.0
635463Ø125×50 mm300 daNC/C 2ZYes63GH 125X50 CC SRP/NL+FA R2.0
635474Ø160×50 mm300 daNC/C 2ZYes63GH 160X50 CC SRP/NL+FA R2.0
635465Ø180×50 mm300 daNC/C 2ZYesThis article
635466Ø200×50 mm300 daNC/C 2ZYes63GH 200X50 CC SRP/NL+FA R2.0
