588414Representative image of the family

Drawing dimensions

Letters as on the drawing. Dimensions from the Tellure Rôta datasheet.

TR-PowerHigh polyurethane fixed castor Ø160×50 mm

Name: Tellure Rôta 588414 · TR-PowerHigh polyurethane fixed castor Ø160×50 mm
Brand: Tellure Rôta
SKU: 588414

TR-PowerHigh polyurethane wheels and drive wheels, cast iron centre

Tellure description: 58GH 160X50 CC SF/EEMHD R2.1

Price on request

Add it to your cart and request a quote: pricing depends on customer profile and volume.

Questions about this article?

Genuine Tellure Rôta product · Made in Italy

TR-PowerHigh polyurethane wheels and drive wheels, cast iron centre

5 articles

Code	Ø × F	Load capacity	Bearing	Brake	Tellure description
588403	Ø125×50 mm	750 daN	C/C 2Z	No	58GH 125X50 CC SF/EEMHD R2.1
588404	Ø150×50 mm	900 daN	C/C 2Z	No	58GH 150X50 CC SF/EEMHD R2.1
588414	Ø160×50 mm	900 daN	C/C 2Z	No	This article
588406	Ø200×50 mm	1,100 daN	C/C 2Z	No	58GH 200X50 CC SF/EEMHD R2.1
588437	Ø250×50 mm	1,250 daN	C/C 2Z	No	58GH 250X50 CC SF/EEMHD R2.1
