624303Representative image of the familyDrawing dimensions
- DDiameter
- 125 mm
- FWidth
- 40 mm
- LHub length
- 40 mm
- LLSeat diameter
- 32 mm
- MBearing housing depth
- 9 mm
Letters as on the drawing. Dimensions from the Tellure Rôta datasheet.
TR-Roll polyurethane wheel Ø125×40 mm
TR-Roll polyurethane wheels, polyamide 6 centre
Tellure description: 62NY 125X40 NY SC 32X9 LM40
- Diameter (D)
- Ø 125mm
- Width (F)
- 40mm
- Load at 4 km/h
- 280daN
- Tread
- TR-Roll polyurethane
Price on request
Add it to your cart and request a quote: pricing depends on customer profile and volume.
Datasheet (PDF)Official Tellure Rôta datasheet (Spanish)
Questions about this article?
Genuine Tellure Rôta product · Made in Italy
Technical specifications
Wheel
- Code
- 624303
- Series
- Tellure Rôta 62NY
- Tread
- TR-Roll polyurethane
- Diameter (D)
- 125 mm
- Width (F)
- 40 mm
- Load at 4 km/h
- 280 daN
- Load at 6 km/h
- 280 daN
- Static load
- 350 daN
- Bearing
- Bearing housing
- Hub length (L)
- 40 mm
- Seat diameter (LL)
- 32 mm
- Bearing seat depth (M)
- 9 mm
Other sizes in this family
TR-Roll polyurethane wheels, polyamide 6 centre
12 articles
| Code | Ø × F | Load capacity | Bearing | Brake | Tellure description |
|---|---|---|---|---|---|
| 622302 | Ø100×40 mm | 230 daN | C/C 2Z | — | 62NY 100X40 CC F15 LM40 |
| 622402 | Ø100×40 mm | 230 daN | C/CX 2RS | — | 62NY 100X40 NY CCX F15 LM40 |
| 624302 | Ø100×40 mm | 230 daN | S/C | — | 62NY 100X40 NY SC 32X9 LM40 |
| 622303 | Ø125×40 mm | 280 daN | C/C 2Z | — | 62NY 125X40 CC F15 LM40 |
| 622403 | Ø125×40 mm | 280 daN | C/CX 2RS | — | 62NY 125X40 NY CCX F15 LM40 |
| 624303 | Ø125×40 mm | 280 daN | S/C | — | This article |
| 622304 | Ø160×50 mm | 400 daN | C/C 2Z | — | 62NY 160X50 CC F20 LM55 |
| 622404 | Ø160×50 mm | 400 daN | C/CX 2RS | — | 62NY 160X50 CCX F20 LM55 |
| 624304 | Ø160×50 mm | 400 daN | S/C | — | 62NY 160X50 SC 47X14 LM55 |
| 622306 | Ø200×50 mm | 500 daN | C/C 2Z | — | 62NY 200X50 CC F20 LM55 |
| 622406 | Ø200×50 mm | 500 daN | C/CX 2RS | — | 62NY 200X50 CCX F20 LM55 |
| 624306 | Ø200×50 mm | 500 daN | S/C | — | 62NY 200X50 SC 47X14 LM55 |
